This 5L Oxygen Concentrator features a sleek, modern design with a slim profile. It combines high-end aesthetics with a simple, user-friendly interface, an ultra-quiet motor, and an advanced cooling system. With low power consumption and a lightweight, durable build, it’s the perfect choice for home use. Its reliability, ease of maintenance, and long-lasting performance also make it ideal for care facilities and professional environments.
Parameter
| Model | FCS-OC-JM05 |
| Compressor | Oil-Free |
| Average Power Consumption | 450 W |
| Input Voltage/Frequency | AC 110V± 10%, 60Hz |
| Ac Power Cord Length (approx.) | 2.5m |
| Sound level | ≤41 dB(A) Typical |
| Outlet Pressure | 5.5 PSI (38 kPa) |
| Liter Flow | 0.5 to 5 L/Min |
| Oxygen Concentration | 93±3% at 5L/Min. |
| Product Dimensions & Weight | 33*26*54cm W: 16Kg(35lbs) G.W: 18.5Kg(40lbs) |
| Operating Temperature | 5 to 40℃ (41 to 104°F) |
| Operating Altitude /Humidity | 0 to 1,828 m, up to 95% relative humidity |
| OPI (Oxygen Percentage indicator) Alarm L Color | Low Oxygen ≤82% (yellow)
Very low Oxygen ≤73% (red) |
| Required Maintenance（Filters） | Inlet window filter cleaning every 2 weeks. Compressor intake filter replacement every 6 months. |
| Alarm Types | System Malfunction, Outage, Impeded Oxygen Flow,
Overload, Overheat, Abnormal Oxygen Concentration |
| Warranty | 3 years or 10,000 hours- Review of manufacturer’s documentation for more details. |
Product Features
A 365-Day, Non-Stop Working Machine
If you rely heavily on oxygen, this 5 LPM oxygen concentrator is your ideal choice. With outstanding compressor performance, it provides a steady, reliable power supply. The large, high-efficiency lithium molecular sieve is designed to meet long-term oxygen production needs. The latest thermal condensation technology helps protect the machine’s service life, while multiple intelligent alarm systems continuously monitor its operation. You can rest assured knowing the concentrator is always performing at its best.
Includes Pressure Sensor Monitor for Stable Oxygen Supply
The concentrator is equipped with a pressure sensor that allows you to monitor the oxygen tank pressure at all times. When the pressure reaches the preset value, the molecular sieve adsorption tower will automatically switch. Unlike time-controlled oxygen production, pressure-sensor monitoring ensures higher purity and more stable oxygen flow. The result is smooth, natural breathing without any uncomfortable sensations.
Includes O₂ Sensor for Enhanced Security
The JUMAO Oxygen Concentrator comes with a built-in O₂ sensor that continuously monitors the oxygen purity. If the oxygen purity drops below acceptable levels, the control panel’s indicator lights will alert you, ensuring that you always receive safe, high-quality oxygen.
Low Maintenance Costs
The concentrator features a simple, user-friendly design, allowing easy access to its internal components. With just four screws—two in the front and two in the rear – you can remove the housing in under 10 seconds for quick maintenance checks.
